| Model | MT-200 |
|---|---|
| Voltage | 110V/220V,50HZ～60HZ |
| Motor Power | 1500W |
| Speed | ≤30 times/min (For reference only) |
| Label Accuracy | ±1mm |
| Bottle diameter | 30-100mm |
| Label Roll Size | Max outer diameter 320mm, Inner diameter 75mm |
| Label Size | Width 30-150mm, Length 30-200mm |
| Dimension | L:214xW:114xH:145cm |
| Weight | 288KGS |
Description:
This automatic vertical round bottle labeling machine is engineered for high-speed, precision labeling of cylindrical containers in the food, pharmaceutical, and chemical industries.
Feature:
PLC control system, touch screen interface, and fiber sensors, it ensures stable performance and intuitive operation
Optional ribbon or ink jet printers allow for simultaneous batch/date coding
Built with stainless steel and aluminum alloy, it meets GMP standards and offers reliable, automated labeling for round bottles
Technical Parameter:
Machine speed | ≤30 times/min (For reference only) |
Power supply | AC110/220V 50/60Hz 1.5KW |
Speed Label Accuracy | ±1mm |
Label Roll Size | Max outer diameter 320mm, Inner diameter 75mm |
Bottle diameter | 30-100mm |
Label Size | Width 30-150mm, Length 30-200mms |
Machine weight | 250 KG |
Machine Dimension | L:214xW:114xH:145cm |
Main configuration list:
No. | Name | Origin | Brands |
1 | PLC | Taiwan | Delta |
2 | AC Contactor | China | CHNT |
3 | Leakage Protection Switch | China | CHNT |
4 | Photoelectric Sensor | Korea | |
5 | Frequency Inverter | Taiwan | Delta |
6 | Touch Screen | Germany | Siemens |
7 | Switch Power | China | Mean well |
8 | Stepper motor | China |
|
9 | Servo motor drivers | China |
|
10 | Conveyor motor | China | TOPPER |
11 | Worm gear reducer | China | TOPPER |
12 | Spoke motors | China | GPG |
Application:
